| Stonewood Clip Overview |
STONEWOOD CLIP SYSTEM BENEFITS
- Factory-machined plank laps conceal clips for a clean look
- Concealed fasteners showcase planks
- Multiple plank sizes: 8”, 12”, 16” (nominal)
- Cost effective solution for plank attachment
- Simplified specification, minimal parts
- Two plank types: Class A, Class B
- Install clips to align with wall studs
- Clips create ventilated facade
- Planks can be cut to width in the field
- FSC® (FSC-C115183) certification available
 |
 |
 |
 |
 |
| Markets We Serve |
|
Architectural Design |
Design Build |
Refresh/Re-Clad |
Preferred Domestic Manufacturer |
| Design Offering |
| Stonewood Clip Plank Sizes |
| Thickness | Panel Size Before Fabrication (Decorative Dimensions) |
Weight Per Plank |
| 5/16" | 7 ⅛” x 96” | 11.5 lbs |
| 5/16" | 11 ¼” x 96” | 17.5 lbs |
| 5/16" | 15 ¼” x 96” | 23.7 lbs |
| Plank-to-Plank Joints |
Maintain a minimum distance of ¼” between planks to
accommodate hygrothermal movement of the plank.
