Vertical Siding Overview

Vertical Siding V Wall with Callout 01

STONEWOOD VERTICAL SIDING BENEFITS

  • Concealed fasteners create a clean look, showcasing planks
  • Ideally suited for accent areas such as soffits
  • Complements other installations of horizontal planks
  • Reduced installation error, no field drilling or threaded fasteners are required to secure planks
  • Uniquely suited for use on large low-rise continuous surfaces
  • Quick and easy installation, kerfed groove plank slides onto corresponding horizontal rail
  • Plank joint placement can vary without additional support structure
  • Simplified specification, minimal parts
  • Two plank types: Class A, Class B
  • Planks can be cut to width in the field
  • FSC® (FSC-C115183) certification available
Modified Width 01 Factory Fabrication Icon 01 Field Fabrication Icon 01
CF Speed icon 4 01 EF Stack Installer 01
Markets We Serve

architectural

Architectural Design

designbuild

Design Build

Tudor BeforeAfter

Refresh/Re-Clad

DomesticLeadTimesweb

Preferred Domestic Manufacturer

Design Offering

Design Offering Thumb

Stonewood Vertical Siding Plank Sizes

PartsOverview Plank Sizes 01



Thickness Panel Size Before Fabrication Weight Per Plank
5/16" 7 ” x 96” 11.5 lbs
5/16" 11 ” x 96” 17.5 lbs
5/16" 15 ¾” x 96” 23.7 lbs
Plank-to-Plank Joints

VS Panel to Panel Joints Image 01

VERTICAL SIDING PLANKS







Maintain a minimum distance of ¼” between planks to
accommodate hygrothermal movement of the plank.

Parts Overview


Parts Overview 1 Full Wall 0050721

Vertical Siding Overview Legend 1 051721

Parts Overview 1 Legend 2 0050721

Installed Panel Overview

Vertical Siding Details Assets 01

Vertical Siding Details Assets 02
